Bizhub 227

SYSTEM SPECIFICATIONS
System memory 2,048 MB (standard)
System hard disk 250 GB (standard)
Interface 10-Base-T/100-Base-T/1,000-Base-T Ethernet; USB 2.0
Wi-Fi 802.11b/g/n (optional)
Network protocols TCP/IP (FTP; SMB; SMTP; WebDAV) (IPv4/IPv6)
Frame types Ethernet 802.2; Ethernet 802.3; Ethernet II; Ethernet SNAP
Automatic document
feeder
Up to 100 originals; A6–A3; 35–128 gsm
RADF optional avaiable
Printable paper size A5–A3; A6S; Thick Paper X/Y size input range: Width:
90–297 mm; Length: 139.7–431.8 mm
Printable paper weight 60–220 gsm
Paper input capacity Standard: 1,100 sheets
Max.: 3,600 sheets
Tray 1 500 sheets; A5–A4; 60–220 gsm
Tray 2 500 sheets; A5–A3; 60–220 gsm
Tray 3 (optional) 500 sheets; A5–A3; 60–220 gsm
Tray 4 (optional) 2 x 500 sheets; A5–A3; 60–220 gsm
Large capacity tray
(optional)
2,500 sheets; A4; 60–220 gsm
Manual bypass 100 sheets; A6–A3; custom sizes; 60–220 gsm
Automatic duplexing A5–A3; 60–209 gsm
Finishing modes
(optional)
Ofset; group; sort; staple; punch; centre-fold; letter fold;
booklet
Output capacity
(with finisher)
Max.: 3,300 sheets
Output capacity
(without finisher)
Max.: 250 sheets
Stapling Max.: 50 sheets or
48 sheets + 2 cover sheets (up to 209 gsm)
Stapling output capacity Max.: 1,000 sheets
Letter fold Up to 3 sheets
Letter fold capacity Max.: 30 sheets (tray); unlimited
Booklet Max.: 20 sheets or
19 sheets + 1 cover sheet (up to 209 gsm)
Booklet output capacity Max.: 100 sheets (tray); unlimited
Copy/print volume
(monthly)
Rec.: 10,000 pages
Max.1: 19,000 pages
Toner lifetime 23,000 pages
Imaging unit lifetime 80,000 pages/600,000 pages (Drum/Developer)
Power consumption 220–240 V / 50/60 Hz; Less than 1.5 kW (system)
System dimensions
(W x D x H)
585 x 660 x 735 mm (Standard coniguration of main body)
System weight Approx. 56.5 kg

COPIER SPECIFICATIONS
Copying process Electrostatic laser copy; indirect
Toner system Simitri® HD polymerised toner
Copy/print speed A4 Up to 22 ppm
Copy/print speed A3 Up to 14 ppm
Autoduplex speed A4 Up to 22 ppm
1st copy out time 5.3 sec.
Warm-up time Approx. 20 sec.2
Copy resolution 600 x 600 dpi
Gradation 256 gradations
Multicopy 1 – 9,999
Original format A5 – A3
Magnification 25–400% in 0.1% steps; auto-zooming
Copy functions Chapter; cover and page insertion; proof copy (print and
screen); adjustment test print; digital art functions; job setting
memory; poster mode; image repeat; overlay (optional);
stamping
¹ If the maximum volume is reached within a period of one year, then a maintenance
cycle must be performed
2 Warm-up time may vary depending on the operating environment and usage 10/2015
Konica Minolta Business Solutions Europe GmbH Europaallee 17 30855 Langenhagen Germany www.konicaminolta.eu

PRINTER SPECIFICATIONS
Print resolution 1,800 (equivalent) x 600 dpi
Page description
language
PCL 6 (PCL 5 + XL 3.0); PostScript 3 (CPSI 3016); XPS
Operating systems Windows VISTA (32/64)
Windows 7 (32/64)
Windows 8 (32/64)
Windows 8.1 (32/64)
Windows 10 (32/64)
Windows Server 2008/2008 R2 (32/64)
Windows Server 2012/2012 R2 (64)
Macintosh OS X 10.x
Unix; Linux; Citrix
Printer fonts 80 PCL Latin; 137 PostScript 3 Emulation Latin
Print functions Direct print of PCL; PS; TIFF; XPS; PDF (v1.7); encrypted
PDF iles and OOXML (DOCX; XLSX; PPTX); mixmedia and
mixplex; “Easy Set” job programming; overlay; watermark;
carbon copy print
Mobile Printing AirPrint (iOS); Mopria (Android); Google Cloud Print
(optional); WiFi Direct (optional); Konica Minolta Print
Service (Android); PageScope Mobile (iOS & Android); NFC
Authentication and Pairing (Android)

SCANNER SPECIFICATIONS
Scan speed (with
optional document
feeder) (mono/colour)
Up to 45 ipm
Scan resolution Max.: 600 x 600 dpi
Scan modes Scan-to-eMail (Scan-to-Me)
Scan-to-SMB (Scan-to-Home)
Scan-to-FTP
Scan-to-Box
Scan-to-USB
Scan-to-WebDAV
Scan-to-DPWS
Network TWAIN scan
File formats TIFF; PDF; Compact PDF; JPEG; XPS; Compact XPS; DOCX;
XLSX; searchable PDF; PDF/A; linerarized PDF
Scan destinations 2,100 (single + group); LDAP support
Scan functions Annotation (text/time/date) for PDF; up to 400 job programs;
Realtime scan preview

FAX SPECIFICATIONS
Fax standard G3
Fax transmission Analogue
i-Fax
Colour i-Fax (RFC3949-C)
IP-Fax
Fax resolution Max.: 600 x 600 dpi (ultra-ine)
Fax compression MH; MR; MMR; JBIG
Fax modem Up to 33.6 Kbps
Fax destinations 2,100 (single + group)
Fax functions Polling; time shift; PC-Fax; receipt to conidential box;
Receipt to e-mail/FTP/SMB; up to 400 job programs

USER BOX SPECIFICATIONS
Max. storable
documents
Up to 3,000 documents or 10,000 pages
Type of user boxes Public
Personal (with password or authentication)
Group (with authentication)
Type of system boxes Secure print
Encrypted PDF print
Fax receipt
Fax polling
User box functionality Reprint; combination
Download
Sending (e-mail/FTP/SMB and fax)
Copy box to box

SYSTEM FEATURES
Security ISO15408/IEEE 2600.2 compliant (in evaluation);
IP iltering and port blocking;
SSL2; SSL3 and TSL1.0 network communication;
IPsec support; IEEE 802.1x support; user authentication;
Authentication log; secure print;
Hard disk overwrite (8 standard types);
Hard disk data encryption (AES 256);
Memory data auto deletion; Conidential fax receipt;
Print user data encryption
Accounting Up to 1,000 user accounts; Active Directory support
(user name + password + e-mail + smb folder)
User function access deinition
Biometric authentication (inger vein scanner) optional
ID card authentication (ID card reader) optional
Software PageScope Net Care Device Manager
PageScope Data Administrator
PageScope Box Operator
PageScope Direct Print
Print Status Notiier
Driver Packaging Utility
Log Management Utility
